Alpinetech LXL-22 22mm 1NO Momentary Push Button Switch 12V, 24V, 110V or 220V LED Illuminated
1. Panel Cutout Hole Diameter - 22mm; Button Diameter - 1" inch
2. Bulb Type - LED; LED Color - Red, Green, Blue or Yellow
3. LED Lamp Voltage - 12VDC, 24VDC, 110VAC or 220VAC
4. Contact Type : 1NO, 1NC (optional); Action Type : Momentary; Insulation Voltage: Ui 600V; Thermal Current: 1th 10A; Short-Circuit current: 1000A; Contact resistance: 50 mΩ max.
5. (Rating) AC-15: 120V 6A, 240V 3A; AC-12: 480V 1.5A, 600V 1.2A; DC-12: 120V 2.2A, 240V 0.6A, 480V 0.4A
6. Safety Standards - UL listed, CSA Certified and TUV Approved; Made in Taiwan
7. Industrial Grade for Tough Environment. (Life) Push button: 1 million operations; (Life) Contact blocks: 1 million operations; IP Enclosure: IP65
8. Modular Design for Easy Installation and Wiring
Package Includes: One 22mm Push Button Switch
